Produkt-Portfolio of 1ST-embedded GmbH

In order to make it easier for you to use our products, we allow you to select and order sample quantities and small quantities of our products in our B2B shop with a selection of variants predetermined by us. For other configurations as well as for serial numbers and framework contracts please contact us or ask us for a separate offer. To get access to our shop, please contact us. kontaktieren Sie uns bitte bzw. fragen Sie uns nach einem separaten Angebot. Um die Zugangsdaten zu unserem Shop zu erhalten nehmen Sie bitte mit uns Kontakt auf.

Of course, regardless of the number of pieces you can always contact us with your questions. We try to give you the best support for your project and we look forward to hearing from you by phone, email or via our contact form.

Please understand that our offer is aimed exclusively at companies, traders and public institutions. The prices listed here are net plus VAT and shipping costs from Hamburg.

Sale
Fanless Industrial Computer BIS-6920H
Fanless industrial computer with Intel® Core™ Processor 6.th Gen. ( Skylake) or 7.th Generation (Kabylake), 2xLAN, 2xSATA3.0, 4xUSB2.0, 4x USB3.0, 10x COM, VGA, DVI & DP, Audio Mic-In and Line-Out, 1 x mSATA, 1x miniPCIE for WiFi or 3G/4G, 1x SIM-card-Socket, 2 PCI-Expansion slots, 4GB DDR4 onboard RAM, 1x DDR4 DRAM Socket for up to 16 GB DDR4-RAM, 0...60°C Operating temperature range, 12V DC 120W Power supply.
Sale
Fanless Industrial Computer 1ST-IXAPL-35
Fanless embedded computer with Intel® Apollo Lake SoC, DDR3L SO-DIMM for up to 8GB DRAM, 2x Gb Ethernet, 4x USB2.0, 4x USB3.0, HDMI + Display Port, SATA3.0, M2 2242 for SSD, EMMC, 4x RS-232, 2x RS-485, 9-24V DC In
Sale
Fanless Industrial Computer 1ST-IXKL-35
Fanless Industrial Computer 1ST-IXKL35 is based on Kaby Lake-U SoC and supports Celeron® 3865U, Core™ i3-6100U, i3-7100U, i5-6200U, i5-7200U, i5-7300U or i7-7500U SoC, Dual Channel DDR4 up to 32GB, 2x 10M/100M/1000M Base T Gigabit LAN, HDMI + DP, SATA3, M.2 2242 for SATA SSDs or 4G, M.2 for WiFi, 4x USB3.0, 4x USB2.0, 4x RS232, 2x RS485, 9 -24 V DC Power input, 165mm x 125mm x 65mm
Sale
Industrial computer KMDA-3602
Industrial computer with 7.th Gen. Intel® Core™ processor, Q170 chipset, 2 DDR4 SO-DIMM-Sockets, 3x LAN, 4x PoE, 6x USB3.0, 3x USB2.0, 1x MXM 3.1 Socket for NVIDIA/AMD GPU-modules, Display Interfaces without GPU-module: 1x DP, 1x HDMI, 1x VGA / with GPU-module additional 3x DP, 1x HDMI; 2x COM, 16 Bit isolated Digital I/O, 2x miniPCIe, 1x M.2 2242 Key B, 1x mSATA, 1x SATA3 2,5" HDD-Bay, 6-48 V DC with ITPS funktionality, anti-vibration design.
Sale
Ultra Thin Fanless Computer 1ST-UTFC-30A
Ultra-Thin-Fanless-Computer based on Intel® Apollo Lake platform with 3xLAN and 2x HDMI and 1x DP, 2x USB3.0, 4x USB2.0, 2x COM, 2 SO-DIMM slots for up to 8 GB DDR3L RAM, 1x SATA, mSATA, 1x Mini-PCIe for WiFi or 3G/4G Modem, Micro-SIM-card Slot, high-quality aluminium housing, 150x190x29mm
Sale
Ultra Thin Fanless Computer 1ST-UTFC30K
Ultra-Thin Fanless Computer with Intel® Core™ i5-7200U Kaby Lake CPU, 2x GBE LAN-ports, HDMI and Display Port, 4x USB2.0, 2x USB3.0, 1x COM, Mic-In, Audio-Out, USB Type C-Connector, m.2 2242 for SSD/4G and m.2 2242/2280 for SSD, m.2 2230 for WiFi/Bluetooth, Micro-SIM-Slot, 2 DDR4-SO-DIMM-Slots for up to 32 GB RAM, 0 ... +60°C operating Temperature, 150x190x30mm, Aluminium housing, black color
Sale
Fanless Industrial Computer KMDA-3601
Fanless industrial computer with Intel® Q170 chipset and Skylake or Kaby Lake Core™ processor, 3x LAN or 7x LAN (7x GBE or 3xGBE + 4xPoE) or 11x LAN, Dual 4K display, 6x USB3.0, 2x USB2.0, 16 Bit Digital IO (isolated), 4x COM, Autio out and mic. in, 2x miniPCIe (PCIe + USB), 1x M.2 2242 Key B, 1x mSATA, 2x 2,5" SATA, RAID 0, Raid 1 support, Intel® vPro™ and TPM2.0, wide Power Input 6 - 48V DC
Sale
i.MX6 embedded board EMB-3501
i.MX6 -S/DL/Q based embedded board with 1GB RAM and 8GB Flash onboard, VGA, HDMI, LVDS multi Display interface, 5xCOM, 2xSATAII, 1xMicro SD slot, 5xUSB2.0, 1xUSB OTG, 1xLAN,
Line out + Line in+ MIC in, power amplifier, 2x5 W 2Ω audio, 1x Mini PCIe for 3G-Module,1xSIM socket, 18-bit GPIO, Operating Temperature: -20 ...+60°C, Dimensions: 146mmx102mm
Sale
Industrial 3G/4G Router UR71
The UR71 is an affordable industrial-grade 4G LTE router designed for connecting Ethernet and RS-232/485 devices to a cellular network.
It is ideal for typical applications including remote installations like kiosks, point of sales and lottery terminals.
Sale
Industrial 3G/4G Router UR51
Ursalink UR51 is a compact and cost-effective Industrial Cellular Router offering 1 Fast Ethernet port for wired connection and global 2G/3G/4G LTE cellular networks for primary or backup Internet access. Features PoE output makes UR51 ideal for light-industrial applications like Kiosk, Video Serveillance, Smart Vending, etc.
Sale
Industrial 3G/4G Router UR55
Industrial Cellular Router UR55 with 5x 10/100Mbit/s RJ45 Ethernet ports, global 2G/3G/4G network support, built in serial ports and Digital I/O for various industrial applications
Sale
Industrial 3G/4G Router UR52
Industrial Cellular Router UR52 with 2x 10/100Mbit/s RJ45 Ethernet ports, global 2G/3G/4G network support, built in serial ports and Digital I/O for various industrial applications
Sale
Fanless Industrial Box-PC BIS-6680H
Fanless Industrial PC with Intel® Core™ processor 7.th Gen. (Kaby Lake), 2x LAN, 2x SATA3.0, 4x USB2.0, 4x USB3.0, 10x COM, VGA & DP, Audio Mic-In and Line-Out, 1x mSATA, 1x miniPCIe for WiFi or 3G/4G, 1x SIM-card-Socket, 0...60°C operating temperature range, 12V DC 120W Power supply.
Sale
C29 Extension Twin Cable 5m SMA Plug to SMA Jack
C29 Extension Twinkabel 5m SMA male to SMA female
Cable Type: SR1-029-B-T
Resistance: 50 OHM +/- 2 OHM @ 1GHz
50 OHM +/- 4 OHM @ 2GHz
Loss: 3dB / 10m @ 1GHz
4.5dB / 10m @ 2GHz
Cable diameter: 2x5mm
Outer jacket: Black Flexible PVC
Foil braid shielding: aluminum foil / tinned copper
Insulation: white polyethylene
Inner conductor: copper
Length: 5m
Connection side 1: SMA plug (m)
Connection side 2: SMA jack (f)
Sale
C29 Extension Twin Cable 10m SMA plug to SMA jack 2C29SP-10SJ
C29 Extension Twinkabel 10m SMA male to SMA female
Cable Type: SR1-029-B-T
Resistance: 50 OHM +/- 2 OHM @ 1GHz
50 OHM +/- 4 OHM @ 2GHz
Loss: 3dB / 10m @ 1GHz
4.5dB / 10m @ 2GHz
Cable diameter: 2x5mm
Outer jacket: Black Flexible PVC
Foil braid shielding: aluminum foil / tinned copper
Insulation: white polyethylene
Inner conductor: copper
Length: 10m
Connection side 1: SMA plug (m)
Connection side 2: SMA jack (f)
Sale
LTE-MiMo-Antenna WMM8G-7-27-5SP
LTE MiMo-Ant. 698-2700MHz 8dbi with 5m Twin-Cable with SMA (m) connectors
The WMM8G-7-27 is a high gain directional 2x2 MIMO antenna for 2G, 3G and 4G networks. (fully compatible with LTE, UMTS, HSDPA, GPRS, EDGE) Two separately fed wideband elements in a single housing provide client side MIMO and diversity support.
The rugged, weatherproof and UV-resistant housing is optimized for wall and mast mount.
Appropriate Brackets are included.
A 5 meter long, double-shielded (low loss) twin cable, with high-quality connectors, allows easy installation and cable routing.
Frequencies:
Element1: 698-960MHz, 1710-2700MHz
Element2: 698-960MHz, 1710-2700MHz
Gain:
@ 698-960MHz 6dBi
@ 1710-2170MHz 9dBi
@ 2396-2700MHz 6dBi
Polarization: Vertical
Radiation pattern: Directional
Dimensions: height 230mm / width 180mm / depth 94mm
Material: UV-resistant ASA plastic
Color: RAL9010 (pure white)
Mounting: wall-mounted / pole-mounted / table-mounted
Cable Type: SR1-029-B-T
Cable length: 2x 5m
Connectors: SMA plug (m)
Sale
2G/3G/4G Terminal Antenna PWB-BC3G-26-RSMAP
2G/3G/4G Terminal antenna / ground plane independent
Frequency: 689-960/1710-2170 MHz, 2396-2700 MHz
Gain: 2dBi/0dBd
Polarisation: vertical
Pattern: Omni-directional
VSWR: <2,5:1
Impedance: 50 OHM
Max Input Power: 10W
Dimensions (mm): Length: 163 / Width: 22 / Thickness: 7
Material: ABS
Colour: Black
Termination Data: Articulated SMA (m) connector
Sale
IEC-95N8
High performance NIC module, based on Dual Intel 82580EB GbE Controller, PCIe x8 bus, 8x RJ-45 ports
Intel I/O interface 3.0 version acceleration technology
Maximum 9.5KB packet Jumbo Frame, supports enhanced VMDq1, up to 8 virtual hosts per port
DCA Directly access with high speed cache
UDP, TCP and IP Checksum offload, UDP and TCP Transmit Segmentation Offload (TSO), SCTP receive and transmit checksum offload
OS-support for WindowsXP/2003, Windows7, RedHat and SuSE Linux, Ubuntu, FreeBSD OS
Typical power consumption: 8.4W
Sale
IEC-95W2
NIC Module with Intel® 82599ES10Gb ethernet controller, two SFP 10Gb ports, PCIe x8 bus
Intel® I/O interface 3.0 version acceleration technology
Supports 15.5KB packet Jumbo Frame for faster and higher data throughput
Supports VMDQ, every port supports 64 virtual hosts
DCA Directly access with high speed cache, Dynamic interrupt moderation
Supports IP/TCP and IP/UDP receive checksum offload, Fragmented UDP checksum offload for packet reassembly, TCP Timer interrupts
Supports Data Center Bridging (DCB), MSI and IPV6
OS-support for WindowsXP/2003, Windows7, RedHat and SuSE Linux, Ubuntu, FreeBSD
Sale
IEC-95F4-040
NIC-Module with Intel® 82580EB GbE controller, 4xSFP, PCIEx4 bus
Intel® I/O interface 3.0 version acceleration technology,
Supports 9.5KB packet Jumbo Frame,
Supports VMDQ1, Up to 8 virtual hosts per port
DCA Directly access with high speed cache
UDP, TCP and IP Checksum offload, UDP and TCP Transmit Segmentation Offload (TSO), SCTP receive and transmit checksum offload
Supports low power consumption power management in network non-working state
Supports WindowsXP/2003, Windows7, RedHat and SuSE Linux, Ubuntu, FreeBSD OS
